Flange Type – ANSI, DIN EN, AS/BS

Material: Monel K500, Inconel X750

Applications: Liquid, Gas & Oxygen Service

Working Temperature: -196°C to + 190°C

Max Working Pressure: 150# – 1.90 Mpa (276 psi), Non-Shock Cold

Max Working Pressure: 300# – 4.96 Mpa (720 psi), Non-Shock Cold

Standards:

Designed in accordance with EN12516 part 1, 2 & 4, EN1626, AS1210, ASME B16.34
End Connection: ASME B16.34, ASME B16.5, AS 2129, BS 4504, EN 1092, ISO 7005, DIN 2501
Tested to ISO 5208, API 598
CE, Pressure Equipment Directive (97/23/EC)

Notes: Degreased, Packed and labelled for Oxygen Services. Face to face connection: RF Various materials (Monel) are available upon request. Mounting options: lever, gearbox and actuator Various threaded end connection are available
